| 48V 17Ah Lithium Battery Pack | |||
| Item | Index | Remark | |
| Basic Spec | Rated Capacity | 17Ah | 2A charge and 5A discharge |
| Norminal Voltage | 48V | ||
| Weight | 6.5±0.1kg | ||
| Dimension | 90*98*361mm | ||
| Cell | ICR18650-2900 | 3.7V 2.9Ah | |
| Configuratioin | 13S5P | ||
| Charge Performance | Charge Mode(Standard) | CC/CV | Fast Charge Current 10A |
| Charge Current(Standard) | 2A | ||
| Charge Voltage(Standard) | 54.6V | ||
| Discharge Performance | Discharge Current(standard) | 5A | Discharge cut-off Voltage 36V |
| Max.Continuous Discharge Current | 20A | ||
| Pulse Discharge Current>10S | 40A | ||
| Storage Condition | Short Term(One month) | (-20℃～ 60℃) | |
| Medium Term(6 months) | (-20℃～ 45℃) | ||
| Long Term(Within 12 months) | (-20℃～ 35℃) | ||
| Cycly Times | More than 500 cycles(Cycle life at 80% rated capacity) | ||
| BMS Function | Protection function of over-charge,over-discharge,over-heat, auto-balance battery cells,over-current and short circuit | ||
